Flying Pages

<canvas id="sky" width="480" height="270"></canvas>
<script type="module">
const device = await (await navigator.gpu.requestAdapter()).requestDevice();
const COUNT = 768, { STORAGE, UNIFORM, COPY_DST } = GPUBufferUsage;
const init = new Float32Array(COUNT * 8);          // 8 floats per page, all zero...
for (let i = 0; i < COUNT; i++) init[i * 8 + 6] = -3 * i / COUNT;   // ...and staggered ages
const pages = device.createBuffer({ size: init.byteLength, usage: STORAGE | COPY_DST });
device.queue.writeBuffer(pages, 0, init);
const sim = device.createBuffer({ size: 16, usage: UNIFORM | COPY_DST });
const code = await (await fetch('pages.wgsl')).text();
const module = device.createShaderModule({ code });
const format = navigator.gpu.getPreferredCanvasFormat(), context = sky.getContext('webgpu');
context.configure({ device, format, alphaMode: 'opaque' });
const update = device.createComputePipeline({ layout: 'auto', compute: { module } });
const blend = { srcFactor: 'one', dstFactor: 'one-minus-src-alpha' };   // premultiplied
const draw = device.createRenderPipeline({ layout: 'auto', vertex: { module },
  fragment: { module, targets: [{ format, blend: { color: blend, alpha: blend } }] },
  primitive: { topology: 'triangle-strip' } });
const group = (pipeline) => device.createBindGroup({ layout: pipeline.getBindGroupLayout(0),
  entries: [pages, sim].map((resource, binding) => ({ binding, resource })) });
const [updateGroup, drawGroup] = [group(update), group(draw)];   // pages.wgsl: Section 4.18.3
let frame = 0;
function tick() {
  const u = new Float32Array([1 / 60, frame / 60, sky.width / sky.height, 0]);
  new Uint32Array(u.buffer)[3] = frame;
  device.queue.writeBuffer(sim, 0, u);
  const encoder = device.createCommandEncoder(), compute = encoder.beginComputePass();
  compute.setPipeline(update), compute.setBindGroup(0, updateGroup);
  compute.dispatchWorkgroups(COUNT / 64), compute.end();   // simulate: no read-back
  const pass = encoder.beginRenderPass({ colorAttachments: [{ loadOp: 'clear',
    storeOp: 'store', view: context.getCurrentTexture().createView(),
    clearValue: [0.07, 0.16, 0.29, 1] }] });
  pass.setPipeline(draw), pass.setBindGroup(0, drawGroup);
  pass.draw(4, COUNT), pass.end();                   // one instanced draw, 768 quads
  device.queue.submit([encoder.finish()]);
  if (++frame < 150) requestAnimationFrame(tick);    // 2.5 simulated seconds, then stop
  else device.queue.onSubmittedWorkDone().then(() => { window.__done = true; });
}
requestAnimationFrame(tick);
</script>
